| Brand | Stûv |
|---|---|
| Models | 16-58 V / 16-68 V / 16-78 V |
| Type | Freestanding Wood Stove (V) |
| Heating Area | 1,400 / 1,650 / 2,100 sq ft |
| Certifications | EPA, UL/ULC, CSA B415.1-22 |
| Special Feature | 16-78 V: Canada only |
| Installation Compliance (QC) | CSA B365 (solid fuel appliances) |
The Stûv 16-V — freestanding wood stove, designed for today’s interiors
Pure and timeless, the Stûv 16-V puts the flame front and center with a large glass panel without visible handle and automatic SBR (single burn rate) control: you light it, it takes care of the rest. Available in three widths (58/68/78), it offers a generous view of the fire, high performance and a freestanding installation that frees up floor space.
• 3 sizes: 16-58 V, 16-68 V and 16-78 V (the 16-78 V is offered in Canada only).
• EPA output: 27,015 / 23,727 / 27,092 BTU/h. Max. output: 65,000 / 82,000 / 86,000 BTU/h. Efficiency (EPA): 71% / 66% / 67%. Emissions: 1.5 / 1.7 / 1.8 g/h.
• Estimated heating area: 1,400 / 1,650 / 2,100 sq ft. Firebox volume: 1.6 / 1.9 / 2.2 cu ft.
• Logs up to 17″ (58), 21″ (68), or 25″ (78). Glass (W × H): 17 5/8″ × 16 9/16″, 21 5/8″ × 16 9/16″, 25 1/2″ × 16 9/16″.
• Venting: 6″ or 7″ chimney; outside air intake Ø 4″ (ideal in airtight homes).
• Certifications: EPA, UL/ULC, CSA B415.1-22. (Installation in Québec per CSA B365 for solid-fuel-burning appliances.)
The 16-V delivers abundant heat with a nominal output of 46,000 / 50,000 / 58,000 BTU/h depending on size, while maintaining a low emission rate (1.5–1.8 g/h). SBR air management optimizes combustion and glass cleanliness for a clear view of the fire day after day.
Vertical venting in 6″ or 7″; minimum clearances specified by Stûv: 7″ rear, 12″ sides (15″ in an alcove), 24 1/2″ ceiling. Ø 4″ outside air intake. Entrust installation to a certified installer and comply with the CSA B365 solid-fuel-burning appliance installation code.
Clean combustion, minimal ash; regular glass cleaning recommended. Manufacturer warranty: To be confirmed according to Stûv America conditions (parts/paint/glass). Document annual maintenance to preserve performance and compliance.
| Specifications | Stûv 16-58 V | Stûv 16-68 V | Stûv 16-78 V |
|---|---|---|---|
| EPA Output (BTU/h) | 27,015 | 23,727 | 27,092 |
| Nominal Output (BTU/h) | 46,000 | 50,000 | 58,000 |
| Maximum Output (BTU/h) | 65,000 | 82,000 | 86,000 |
| Efficiency (EPA) | 71% | 66% | 67% |
| Emissions (g/h) | 1.5 | 1.7 | 1.8 |
| Heating Area (sq ft) | 1,400 | 1,650 | 2,100 |
| Firebox (cu ft) | 1.6 | 1.9 | 2.2 |
| Max. Log Length | 17″ | 21″ | 25″ |
| Dimensions (W × D × H) | 24 13/16″ × 20″ × 35 9/16″ | 28 13/16″ × 20″ × 35 9/16″ | 32 13/16″ × 20″ × 35 9/16″ |
| Glass (W × H) | 17 5/8″ × 16 9/16″ | 21 5/8″ × 16 9/16″ | 25 1/2″ × 16 9/16″ |
| Chimney diameter | 6″ or 7″ | 6″ or 7″ | 6″ or 7″ |
| Outside air intake | Ø 4″ | Ø 4″ | Ø 4″ |
| Min. Clearances (rear / sides / ceiling) | 7″ / 12″ (15″ alcove) / 24 1/2″ | 7″ / 12″ (15″ alcove) / 24 1/2″ | 7″ / 12″ (15″ alcove) / 24 1/2″ |
| Weight | 267 lb | 289 lb | 318 lb |
| Availability | Canada & USA | Canada & USA | Canada only |
Come see the Stûv 16-V in operation in our Noréa Foyers Montréal & Rive-Nord / Noréa Foyers Rive-Sud showrooms. We will validate your configuration (size, clearances, 6″/7″ flue, air intake) and prepare an installed quote compliant with CSA B365.
Stûv 16-V is the wood stove on legs that combines clean aesthetics with proven performance: up to 86,000 BTU/h, 66–71% efficiency, logs up to 25″, 6″ or 7″ chimney, and Ø 4″ air intake. EPA / CSA B415.1 certified. Three sizes (58/68/78) for premium residential projects, installed in Québec per CSA B365.
Oui, lorsque l’installation respecte le manuel et la gestion de chaleur Cool Touch Wall, qui permet de réduire la chaleur en façade pour abaisser le téléviseur plus près du foyer. Les schémas de montage TV et exigences de rejets/chaleur sont détaillés par Flare; toujours suivre le manuel d’installation et la configuration de heat-release recommandée.
Le ST-45 est un foyer à évent direct (système coaxial scellé). La fiche technique liste un raccord 4×6 en configuration naturelle, et 3×5 avec power vent. Le manuel couvre les parcours, terminaisons horizontales/verticales et les dégagements au conduit. Un installateur qualifié doit valider le tracé sur place.
La puissance d’entrée maximale est de 36 000 BTU/h en gaz naturel (GN) et 28 000 BTU/h en propane (PL). Le fabricant annonce une efficacité jusqu’à 82 % (GN) / 83 % (PL). Les performances réelles varient selon la configuration, le réglage et la qualité d’évacuation.
Flare indique une certification CSA pour l’installation en Amérique du Nord. La garantie prévoit 18 mois sur l’électronique, 5 ans sur les vitrages (bris thermique) et 10 ans limités sur la boîte foyère et les brûleurs. Au Québec, l’installation du gaz doit respecter le Code CSA B149.1 et le manuel du fabricant.
