| Type |
Electric |
|---|
| Type |
Fireplaces |
|---|
| Brand | Dimplex |
|---|---|
| Model | Optimyst Pro Box (GBF1000-PRO, GBF1500-PRO) |
| Specifications | Built-in electric water vapor fireplace (Optimyst) |
| Energy | 120 V Electricity |
| Power/Heat | ~1,460–1,490 W; ~4,981 BTU/h (supplemental) |
| Dimensions (GBF1000-PRO) | 46 5/8" × 31 3/4" × 16 1/4" |
| Dimensions (GBF1500-PRO) | 65 1/8" × 31 3/4" × 16 1/4" – view 58" × 16 1/4" |
| Controls | Flame Connect app, remote control |
With the Dimplex Optimyst Pro Box, the magic of 3D water vapor flames integrates into a built-in firebox ready for residential and commercial projects. Available in 40″ (GBF1000-PRO) and 60″ (GBF1500-PRO), it offers single-sided or see-through installation (by adding the rear glass), discreet supplemental heat, and full control via the Flame Connect app. Ideal for feature walls, hotels, restaurants, or condos in Montreal, with no venting, no gas, and glass that is cool to the touch.
Optimyst Flames: flame and “smoke” effect via ultrasound + lighting (tap water), striking and safe.
Configurable Setup: single or double-sided (removable rear panel, optional rear glass).
Supplemental Heat: integrated fan-forced heater for occasional comfort (up to approx. 400 sq ft).
Power Supply: 120 V, firebox ready for direct wiring (hardwire); typical power ~1,460–1,490 W.
Simplified Maintenance: tank with optional plumbing kit for continuous water supply.
Controls: Flame Connect app (iOS/Android) + remote control, schedules, and guest access.
The Pro Box creates a deep and customizable flame ribbon (spacers and slots provided) to adapt the flame width/shape to the desired design. The supplemental heat remains gentle and even, sufficient to enhance a living room, lobby, or dining room without overheating. The tempered front glass provides a clean finish and reduces air movement around the flames.
Type: built-in electric fireplace (permanent, hardwired). No venting.
Water: fill the tank or connect with the plumbing kit (optional). Avoid drafts (fans, vents).
Electricity: dedicated 120 V circuit recommended based on load; installation by a qualified electrician.
Certifications: manufacturer’s North American electrical certification listings.
Local Standards: electrical product (not subject to CSA B149.1/B365). Comply with the Quebec Building Code (Chapter V – Electricity) and the installation manual.
Water: use clean water; check nozzles/filters periodically.
Cleaning: dust the air intake, wipe the glass.
Warranty: 2-year limited (manufacturer).
| Model | Viewable Width (W × H) | Power Supply | Heating | Dimensions (W × H × D) | Installation Type | Main Options | Controls |
|---|---|---|---|---|---|---|---|
| GBF1000-PRO (40″) | To be confirmed | 120 V, ~1,460 W, ~4,981 BTU/h | Fan-forced (supplemental heat) | 46 5/8″ × 31 3/4″ × 16 1/4″ | Built-in, single-sided or see-through (optional rear glass) | Rear glass GBF1000-GLASS; plumbing kit (continuous water); log kit (CDFILOG) | Flame Connect app + remote control |
| GBF1500-PRO (60″) | 58″ × 16 1/4″ | 120 V, ~1,460–1,490 W, ~4,981 BTU/h | Fan-forced (supplemental heat) | 65 1/8″ × 31 3/4″ × 16 1/4″ | Built-in, single-sided or see-through (optional rear glass) | Rear glass GBF1500-GLASS; plumbing kit (continuous water); log kit (CDFILOG) | Flame Connect app + remote control |
Come see the Optimyst flames in demonstration and validate the opening (1 or 2 sides), trim, and water supply. We offer turnkey quotes (installation, power supply, finishes).
