| Brand | Dimplex |
|---|---|
| Specifications | Water-vapor electric fireplace (Optimyst), built-in |
| Models | FEF3226L1 (1-sided) · FEF3226L2L (2-sided left) · FEF3226L2R (2-sided right) · FEF3226L3 (3-sided) |
| Nominal size | 32" × 26" (800/650 series) |
| Power | 120 V — ≈ 270 W · ≈ 2.25 A (hardwired) |
| Water | ¼" connection · 8–110 psi · ≈ 0.30 L/h |
| Fresh air | ≥ 40 in² under the unit (increase if grille) |
| Controls | remote, Flame Connect app |
The Dimplex Optimyst e-MatriX delivers a spectacular 3D flame created by a fine lit water mist. Designed for zero-vent built-in installation, it comes in three configurations — single-sided, corner (2-sided), or bay (3-sided) — to integrate a residential media wall or a commercial space without the constraints of a gas fireplace. 120 V, 270 W, cool-to-the-touch glass, ¼” water connection, and the Flame Connect app: everything for a clean, safe installation in Québec.
Optimyst technology: water vapor + LED → ultra-realistic flames and “smoke”, with no scorching-hot glass.
Sizes & configurations (800/650 series “32″ × 26″”): 1-sided (FEF3226L1), 2-sided left/right (FEF3226L2L / L2R), 3-sided (FEF3226L3).
Power: 120 V, ≈ 270 W, ≈ 2.25 A (hardwired). No supplemental heat (ambiance unit).
Water: permanent ¼” connection (8–110 psi), approx. 0.30 L/h consumption; integrated overflow protection.
Fresh air required: provide ≥ 40 in² of intake under the unit (increase if a grille reduces free area).
Controls & comfort: remote + Flame Connect app; optional crackling sounds and a realistic log set.
Designed for ambiance rather than heating, the e-MatriX delivers flame depth and an immersive visual that remains stable when the air supply and water supply meet requirements. Avoid drafts (HVAC vents, fans) that disrupt the flame, as you would with a candle.
Type: water-vapor electric fireplace (built-in, hardwired 120 V). No venting.
Fresh air: min. 40 in² under the unit; clear the area if a grille reduces the opening.
Water: ¼” supply (8–110 psi) + supplied filters; use non-hard water or softened/filtered water.
Standards: electrical product (not subject to CSA B149.1/B365). Follow the Canadian Electrical Code and the manual.
Certifications: cULus marking (ref. E71416 noted), dry indoor use.
Routine: ensure periodic cleaning of nozzles/filters and a clear air intake; check water filters.
Warranty: 2-year limited (manufacturer — Dimplex electric products).
Noréa tip: plan for a dedicated 15 A outlet if other loads trip the circuit.
| Model | Configuration | Nominal size | Power supply | Water consumption | Fresh air required | Water connection | Controls / options |
|---|---|---|---|---|---|---|---|
| FEF3226L1 | Single-sided | 800/650 (≈ 32″ × 26″) | 120 V · ≈ 270 W · ≈ 2.25 A (hardwired) | ≈ 0.30 L/h | ≥ 40 in² (under the unit) | ¼″ line · 8–110 psi | Remote, Flame Connect app; log set, crackling sounds |
| FEF3226L2L | Two-sided – left corner | 800/650 (≈ 32″ × 26″) | 120 V · ≈ 270 W · ≈ 2.25 A | ≈ 0.30 L/h | ≥ 40 in² | ¼″ line · 8–110 psi | Remote, Flame Connect app; log set, crackling sounds |
| FEF3226L2R | Two-sided – right corner | 800/650 (≈ 32″ × 26″) | 120 V · ≈ 270 W · ≈ 2.25 A | ≈ 0.30 L/h | ≥ 40 in² | ¼″ line · 8–110 psi | Remote, Flame Connect app; log set, crackling sounds |
| FEF3226L3 | Three-sided – bay | 800/650 (≈ 32″ × 26″) | 120 V · ≈ 270 W · ≈ 2.25 A | ≈ 0.30 L/h | ≥ 40 in² | ¼″ line · 8–110 psi | Remote, Flame Connect app; log set, crackling sounds |
Notes: North American e-MatriX “32″ × 26″” models. The unit has no heating; the “heater” mention in compliance notices refers to the product’s electrical category (heat output minimal, not intended for heating).
Come experience the Optimyst effect in our showroom and confirm 1/2/3-sided, fresh air, water supply, and built-in requirements with our experts. Turnkey quote (unit, frame, utilities).
Montréal & North Shore — 950 Bégin, Ville St-Laurent QC H4M 2N5 — 514-254-4131
South Shore — 4175 ch. Chambly, Saint-Hubert QC J3Y 3M5 — 450-445-0041
Dimplex Optimyst e-MatriX: water-vapor fireplace 32″ × 26″ (800/650 series) in 1-sided / 2-sided / 3-sided. 120 V ~ 270 W, ¼” water supply, fresh air ≥ 40 in², Flame Connect app. Professional installation by Noréa GM.
