| Type |
Electric |
|---|
| Type |
Fireplaces |
|---|
| Brand | Dimplex |
|---|---|
| Specifications | Water vapor electric fireplace (Optimyst) |
| Model | Optimyst Aura 28" (3STEP-RGB-AM, part no. 500003866) |
| Energy | 120 V electricity |
| Power / amperage | 1,275 W · 10.63 A |
| Heat | Optional fan-forced, up to ~1,000 sq ft |
| Dimensions (product) | 30" × 29-3/16" × 15-15/16" |
| Viewing area | 28-9/16" × 14-15/16" |
| Controls | Flame Connect (app), remote |
| Certifications | cULus E71416 · UL 2021 / CSA C22.2 No.46 |
The Dimplex Optimyst Aura is a 28″ water vapor electric fireplace that creates an ultra-realistic 3D flame and cool “mist” thanks to an ultrasonic system. Its frameless design, pull-out drawer for water refills, and single-, two-, or three-sided configurations make it a premium solution for modern interiors in Québec, with no gas and no venting (simple, safe installation, cool to the touch).
Optimyst 3D effect: water vapor + RGB LEDs for a realistic flame, cool to the touch. Control via remote and the Flame Connect app.
Built-in supplemental heater (fan-forced) for areas up to ~1,000 sq ft, usable with or without heat depending on the season.
Flexible installation: single-sided, two-sided, or bay; front drawer for water refills without plumbing (optional plumbing kit if desired).
Clean finish: flush front, cool surfaces, and tempered glass for residential or commercial integration.
North American manufacturer (Cambridge, ON) – documentation, parts, and service available in Canada.
Power: 120 V, 1,275 W, 10.63 A.
Modes: Flame only or Flame + heat.
Controls: Flame Connect mobile app, multifunction remote, controls in the drawer.
Easy maintenance: drawer fill; float/overflow safety; accessible filters and nozzles.
(data confirmed by the 3-Part Specs sheet and the Aura installation guide).
Type: built-in Optimyst electric fireplace (water vapor technology). No venting required.
Rough-in: check the air intake (mandatory) – 29 in² at the top and 16 in² at the bottom, unobstructed, for optimal flame performance and heater operation.
Rough-in dimensions (single-sided): W 30 3/8″ × H 29 1/2″ × D 15 15/16″; drywall opening 28 7/8″ × 23 5/8″.
Electrical: 120 V circuit (rated 1,275 W). Follow the Canadian Electrical Code; GFCI required if installed in a bathroom (see manual).
Certifications: cULus E71416, compliant with UL 2021 / CSA C22.2 No.46 (household appliances).
Finish / items above: follow clearance and air-supply recommendations; heat-sensitive items (TV, shelf) per the manual.
Filling: front drawer (tap water recommended per manual); optional plumbing kit for continuous supply.
Cleaning: periodic maintenance of nozzles and filters; check the air intake.
Warranty: 2 years on electrical components (manufacturer).
| Model | Technology | Power (V/W/A) | Heat & coverage | Dimensions (W × H × D) | Viewing area (W × H) | Single-sided rough-in (W × H × D) | Required air (top / bottom) |
|---|---|---|---|---|---|---|---|
| Optimyst Aura 28″ (3STEP-RGB-AM) | Water vapor electric fireplace (Optimyst) | 120 V / 1,275 W / 10.63 A | Fan-forced (optional), up to ~1,000 sq ft | 30″ × 29-3/16″ × 15-15/16″ | 28-9/16″ × 14-15/16″ | 30-3/8″ × 29-1/2″ × 15-15/16″ | 29 in² / 16 in² |
See the Optimyst Aura 28″ on display and confirm the opening type (single-, two-, three-sided), the surround and the air supply for your media wall. We offer the turnkey quote (unit, rough-in, power supply, finishes).
Montréal & North Shore — 950 Bégin, Ville St-Laurent, QC H4M 2N5 — 514-254-4131
South Shore — 4175 ch. Chambly, Saint-Hubert, QC J3Y 3M5 — 450-445-0041
Dimplex Optimyst Aura 28″ (3STEP-RGB-AM): water vapor electric fireplace with a 3D flame that’s cool to the touch, supplemental heat up to ~1,000 sq ft, fill drawer without plumbing, 120 V/1,275 W. Installed by our teams in Québec.
Oui, lorsque l’installation respecte le manuel et la gestion de chaleur Cool Touch Wall, qui permet de réduire la chaleur en façade pour abaisser le téléviseur plus près du foyer. Les schémas de montage TV et exigences de rejets/chaleur sont détaillés par Flare; toujours suivre le manuel d’installation et la configuration de heat-release recommandée.
Le ST-45 est un foyer à évent direct (système coaxial scellé). La fiche technique liste un raccord 4×6 en configuration naturelle, et 3×5 avec power vent. Le manuel couvre les parcours, terminaisons horizontales/verticales et les dégagements au conduit. Un installateur qualifié doit valider le tracé sur place.
La puissance d’entrée maximale est de 36 000 BTU/h en gaz naturel (GN) et 28 000 BTU/h en propane (PL). Le fabricant annonce une efficacité jusqu’à 82 % (GN) / 83 % (PL). Les performances réelles varient selon la configuration, le réglage et la qualité d’évacuation.
Flare indique une certification CSA pour l’installation en Amérique du Nord. La garantie prévoit 18 mois sur l’électronique, 5 ans sur les vitrages (bris thermique) et 10 ans limités sur la boîte foyère et les brûleurs. Au Québec, l’installation du gaz doit respecter le Code CSA B149.1 et le manuel du fabricant.
